Park Tool - BBT-RS Bottom Bracket Tool Retaining System

Park Tool BBT-RS Bottom Bracket Tool Retaining System

Some bottom bracket cups only give a tool a few millimetres of grip, and bottom brackets need a lot of torque. The BBT-RS uses spring tension to hold the tool fully engaged in the fitting so it doesn't slip off mid-turn. It uses an M8 threaded rod and a double-sided adapter nut with M12 and M15 threads, so it threads straight into compatible cartridge bottom brackets.

Works with threaded cup, thread-together, cartridge and cup-and-cone bottom brackets, and with most Park Tool BB tools. Used with the BBT-69.4 it can also remove rotor lockrings on thru-axle hubs up to 148mm wide. A workshop tool for anyone fighting stubborn BBs.

Key Features

• Spring tension keeps the tool fully seated in the fitting
• Adapter nut with M12 and M15 threads
• Works with socket-style, handled and wrench-flat BB tools
• Can remove rotor lockrings on thru-axle hubs up to 148mm with the BBT-69.4

Specifications

• Bottom bracket styles: Threaded cup, thread-together, cartridge, cup-and-cone
• Socket-style tools: BBT-27.3, BBT-35-12, BBT-35-36, BBT-47-12, BBT-47-16, BBT-49.3, BBT-59.3, BBT-69.3, BBT-69.4, BBT-79.3
• Handled tools: e.g. BBT-9, BBT-29, HCW-4
• Wrench-flat tools: e.g. BBT-19.2, BBT-22
• Rod length: 175mm (6.9")
• Rod threading: M8 x 1.0
• Adapter nut threading: M12 x 1.0 and M15 x 1.0
• Speed nut diameter: 38mm (1.5")
• Washer diameter: 57mm (2.25")

Specs can change without notice from Park Tool.
