SRAM DM DROP-STOP CHAINRING - NON-BOOST (6MM OFFSET)

Wolf Tooth Direct Mount Drop-Stop Chainring (Non-Boost, 6mm Offset)

A direct mount chainring for SRAM cranks that replaces your spider and chainring with one machined piece that is lighter and stiffer. This 6mm offset suits standard, non-Boost drivelines. Pick from the variants for 30T or 32T.

Key Features

• Drop-Stop wide/narrow tooth profile for chain retention and mud shedding
• Replaces the ring and spider, or the direct mount ring, on SRAM cranksets including DUB, attached with three bolts at the back of the spider
• 6mm offset gives a 49mm chainline on non-Boost mountain bikes with GXP and long spindle BB30 cranks, or 47mm on road, CX and gravel cranks
• Fat bikes with 170/177 rear hub spacing use the 6mm offset
• Wolf Tooth recommends a clutch rear derailleur for the best chain security
• Reuse your three bolts. Use a T25 L-wrench, as the crank spindle can stop a socket adapter engaging

Specifications

• Offset: 6mm
• Material: 7075-T6 aluminium
• Weight: 30T 65g, 32T 70g
• Made in the USA

Not sure it fits your crank? Talk to us before you buy.
