Clean and Simple is always best. Leverless design for added security and clearance for when situations get tight. These super tough axles tighten up with a 6mm Allen key. They feature “a get out of jail’ 6mm Allen key on the drive side of the axle if you manage to round the non-drive side.

Constructed from 7075 Aluminium and made to the manufacturer’s exact specifications.

Fits:

Santa Cruz:

*Note: The UDH bolt is only compatible with Sram UDH Hanger, not the native SCB Alloy Hanger. The axle itself will still work with the SCB hanger.

• 5010 V4, 5010 V5*
• Blur V4*
• Bronson V4, Bronson V5*
• Bullit V3 MX (E-bike)
• Chameleon V8
• Heckler V9*
• Heckler SL V1*
• Highball V3.1*
• Hightower V2 (MY22+ only), Hightower V3*, Hightower V4*
• Megatower V2*
• Nomad V5, Nomad V6*
• Tallboy V4 (MY22+ only), Tallboy V5*
• Vala V1*
• And Juliana Equivalents

Your bike doesn't show on this list? Try our 168.5mm Rear Axle.

Trek:

• E-Caliber MY21+

Manufacturer's Part Number: HWQASM00S2155S (QR1961)
